Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point

Send Inquiry

Request To Call Back

Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point

Name: Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point
Brand: AIRPATH WIRELESSNET SOLUTIONS
Price: 9400.00 INR
Availability: InStock

Price 9400.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point Specification

Network Device
Other

Features
Wi-Fi 6 (802.11ax), MU-MIMO, OFDMA, IP67 weatherproof, Mesh Capable, Advanced Security

Usage & Applications
Outdoor Wireless Networking, Wi-Fi Hotspots, Business and Campus Deployments

Frequency
2.4GHz & 5GHz dual-band

Interface Type
RJ45 Ethernet

Power Consumption
12.95W Max

Antenna
Built-in, high-gain directional antennas

Power Supply
PoE+ (802.3at) / 12V DC Adapter

Dimension (L*W*H)
213mm x 183mm x 45mm

IP Routing
Supported

Weight
750g (approx.)

Port
1 x 10/100/1000Mbps Gigabit Ethernet

Operating Temperature
-30C to 60C

Remote Control
Yes

Device Type
Outdoor Long Range AX3000 Wi-Fi 6 Access Point

Number Of Ports/Pins
1 Ethernet Port

Connectivity Type
Wireless/Wired

Cable Length
Up to 100 meters (Ethernet)

Management
GWN.Cloud, GWN Manager, Local Web GUI

QoS
Layer 2/3 QoS

LED Indicators
Power/Status/Wi-Fi

Max Number of Clients
Up to 256 concurrent clients

Mounting Options
Pole and Wall Mountable

Security Protocols
WPA3, WPA2, WPA, WEP, 802.1X

Coverage Range
Up to 300 meters (line of sight)

Wireless Speed
Up to 2976 Mbps (AX3000)

VLAN Support
802.1Q VLAN tagging

Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Days

Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point About

GWN Enterprise-Grade 2x2:2 Wi-Fi 6 Weatherproof Long-Range Access Point
The GWN7660ELR is an enterprise-grade long-range Wi-Fi 6 access point that allows businesses to build next-generation Wi-Fi networks for high-density environments.

3 Gbps aggregate wireless throughput, 1 Gbps RJ45, and 2.5 Gbps SFP wireline ports
Dual-band 2x2:2 MIMO with OFDMA technology
Self-power adaptation upon auto-detection of PoE or PoE+
Support 256 concurrent Wi-Fi client devices
Up to 300-meter coverage range
Advanced QoS to ensure real-time performance of low-latency applications
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Flexibility of 5 internal antennas
Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management

High-Performance Outdoor Wi-Fi 6

Equipped with Wi-Fi 6 (802.11ax), the Grandstream GWN7660ELR delivers faster speeds, greater capacity, and improved efficiency compared to previous generations. It supports up to 256 concurrent clients, ensuring seamless connectivity for dense environments. With coverage up to 300 meters (line of sight), it's perfect for expansive outdoor operations.

Rugged, Weatherproof Reliability

With an IP67 weatherproof rating, this access point endures harsh outdoor environments-from -30C to 60C. Its high-gain directional antennas offer powerful, focused coverage, while the durable housing resists dust and moisture. It is an ideal choice for Indian climates and demanding outdoor business applications.

Advanced Security and Easy Management

Protect your network with top-tier security, including WPA3, WPA2, WPA, WEP, and 802.1X protocols. For management convenience, the GWN7660ELR can be controlled via cloud-based GWN.Cloud, centralized GWN Manager, or a local web GUI, providing administrators with flexibility and oversight from anywhere.

FAQ's of Grandstream GWN7660ELR Outdoor Long Range AX3000 Wi-Fi 6 Access Point:

Q: How is the Grandstream GWN7660ELR powered and installed outdoors?

A: The GWN7660ELR supports Power over Ethernet Plus (PoE+, 802.3at) or a 12V DC adapter for flexible installation. Its IP67-rated enclosure and mounting options (pole and wall) allow secure, weatherproof deployment in varied outdoor locations.

Q: What is the maximum coverage and client capacity of this access point?

A: It covers up to 300 meters (line of sight) and supports up to 256 concurrent clients, making it suitable for large outdoor areas, business campuses, or public hotspots requiring high client density.

Q: Where can I manage the GWN7660ELR access point remotely?

A: You can manage the device via GWN.Cloud for cloud-based control, GWN Manager for centralized management, or the local web GUI for on-site administration-ensuring flexible monitoring and configuration options.

Q: What security features does the GWN7660ELR offer?

A: The access point supports advanced security protocols including WPA3, WPA2, WPA, WEP, and 802.1X, along with VLAN tagging. This helps to safeguard your wireless network from unauthorized access and ensure data integrity.

Q: When should I choose this model for my outdoor wireless projects?

A: Opt for the GWN7660ELR when you need reliable, wide-ranging, weatherproof, and high-capacity Wi-Fi for outdoor environments such as campuses, parks, large venues, or hospitality areas in India.

Q: How does the GWN7660ELR improve network efficiency and user experience?

A: With Wi-Fi 6 technology (MU-MIMO, OFDMA), Layer 2/3 QoS, and advanced signal management, the device optimizes bandwidth, reduces latency, and delivers fast, stable connections even with numerous simultaneous users.
