MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router

Send Inquiry

Request To Call Back

MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router

Name: MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router
Brand: AIRPATH WIRELESSNET SOLUTIONS
Price: 35000.0 INR
Availability: InStock

Price 35000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router Specification

Dimension (L*W*H)
444 x 175 x 47 Millimeter (mm)

IP Routing
Supported; Dynamic routing protocols (OSPF, BGP, RIP) via RouterOS

Network Device
Other

Remote Control
Yes

Weight
1.7 kg Kilograms (kg)

Usage & Applications
Enterprise networking, ISP core routing, data center connectivity

Frequency
Tilera 9-core CPU @ 1.2 GHz Hertz (HZ)

Device Type
Advanced Cloud Core Router

Features
No switch-chip, full independent Ethernet ports, hardware encryption, redundant power supply support, LCD display

Port
7x Gigabit Ethernet, 1x Combo port (Gigabit Ethernet/SFP), 1x SFP port

Operating Temperature
0°C to +40°C Celsius (oC)

Power Consumption
Maximum 34W Watt (W)

Interface Type
Gigabit Ethernet, SFP Fiber

Number Of Ports/Pins
9 total (7 Gigabit Ethernet, 1 combo, 1 SFP)

Connectivity Type
Wired; Gigabit Ethernet & Fiber

Cable Length
Depends on type; typically up to 100m for Ethernet Meter (m)

Rack Mountable
Yes, 1U rackmount

MTBF
Approximately 200,000 hours at 25C

USB Port
Yes, USB type A

LCD Panel
Yes, touch screen for status/control

Serial Port
RJ45

Operating System
MikroTik RouterOS, Level 6 license

Storage
128 MB NAND

RAM
2 GB

Redundant Power
Supported; dual DC input

MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Delivery Time
1 Days

Main Domestic Market
All India

About MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router

Backed by a team of adroit professionals, we are engrossed in supplying the top-of-the-line MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router that is widely acclaimed among our customers owing to its resilience, top-notch quality, and reliable performance. It is a powerful Ethernet router based on cutting-edge technology. It supports a smart card in order to store your private key for use in all features that support certificate-based authentication. MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router is easy to install and use.

High-Performance Routing for Modern Networks

With a powerful multi-core processor and MikroTik RouterOS, the CCR1009-7G-1C-1S excels in enterprise, service provider, and data center applications. Its independent Gigabit Ethernet ports and SFP options ensure flexible, high-throughput connectivity for critical network segments.

Comprehensive Management and Monitoring

The routers LCD touchscreen provides intuitive status displays and control, complemented by remote access via Web, WinBox, SSH, and API. Its RouterOS Level 6 license supports dynamic routing protocols, making configuration and network monitoring straightforward for administrators.

Reliable and Versatile Hardware Design

Rack-mountable in standard 1U racks, the CCR1009 also features dual DC power inputs for redundancy, minimizing downtime. Hardware encryption boosts security, while absence of a switch-chip guarantees independent operation of all Ethernet ports.

FAQs of MikroTik CCR1009-7G-1C-1S Advanced Cloud Core Router:

Q: How does the CCR1009-7G-1C-1S benefit enterprise and ISP networks?

A: Its combination of a powerful 9-core CPU, independent Gigabit Ethernet ports, SFP fiber connectivity, and dynamic routing protocol support ensures robust performance, scalability, and flexibility for demanding enterprise and ISP environments, helping maintain reliable and secure connectivity.

Q: What remote management options are supported on this MikroTik Cloud Core Router?

A: The router can be managed remotely using MikroTik RouterOS interfaces such as Web, WinBox, SSH, or API, allowing network administrators to monitor, configure, and troubleshoot the device from virtually anywhere.

Q: When is redundant power supply beneficial for router operations?

A: Redundant power is critical for minimizing downtime in mission-critical networks. The CCR1009 supports dual DC power inputs, offering automatic failover to maintain network stability in event of a power source failure.

Q: Where is the CCR1009-7G-1C-1S commonly installed?

A: This model is typically rack-mounted in data centers, enterprise wiring closets, or ISP core networks across India and other regions needing high-performance, reliable routing solutions.

Q: What is the process for setting up dynamic routing protocols like OSPF or BGP?

A: Dynamic routing protocols are configured via MikroTik RouterOS, using its graphical interface (WinBox/Web) or command line (SSH). Administrators can set up OSPF, BGP, or RIP and adjust settings according to network topology and requirements.

Q: How can the LCD touchscreen be used for router status and control?

A: The built-in LCD panel displays real-time status, network statistics, and alerts, while the touchscreen functionality allows direct interaction for basic configuration tasks and device monitoring without needing an external computer.

Q: What is the maximum cable length for Ethernet connections with this router?

A: The maximum cable length for Gigabit Ethernet ports is typically up to 100 meters, depending on cable quality and type, allowing flexible deployment in medium to large network infrastructures.
