USW 24 POE

About USW 24 POE

Features:

The USW-24-POE is a configurable Gigabit Layer 2 switch with twenty four Gigabit Ethernet ports including sixteen auto-sensing 802.3at PoE+ ports, and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-24-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.

Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.

• 24 x RJ45 Ports
• 16 x PoE Ports
• 8 x Gigabit RJ45 Ports
• 2 x 1G SFP Ports
• Total Available PoE - 95W
• Max. PoE Wattage per Port - 32W
• Switching Capacity - 52 Gbps
• Forwarding Rate - 8.69 Mpps
• Total Non-Blocking Throughput = 26 Gbps
• Near Silent Cooling
• 1.3 " Touchscreen Display
• SFP Support - Fibre links of up to 1 Gbps
• Tested ambient temperature - -5C to 40C
